ns3::SatIslArbiter Class Reference

#include "satellite-isl-arbiter.h"

Inheritance diagram for ns3::SatIslArbiter:

Collaboration diagram for ns3::SatIslArbiter:

Public Member Functions
	SatIslArbiter ()
	Default constructor. More...
	SatIslArbiter (Ptr< Node > node)
	Constructor. More...
int32_t	BaseDecide (Ptr< Packet > pkt, Mac48Address destination)
	Base decide how to forward. More...
virtual int32_t	Decide (int32_t sourceSatId, int32_t targetSatId, Ptr< Packet > pkt)=0
	Decide how to forward. More...
virtual std::string	StringReprOfForwardingState ()=0
	Convert the forwarding state (i.e., routing table) to a string representation. More...

Static Public Member Functions
static TypeId	GetTypeId (void)

Protected Attributes
uint32_t	m_nodeId

Detailed Description

Definition at line 37 of file satellite-isl-arbiter.h.

Constructor & Destructor Documentation

SatIslArbiter() [1/2]

ns3::SatIslArbiter::SatIslArbiter

(

)

Default constructor.

Definition at line 43 of file satellite-isl-arbiter.cc.

SatIslArbiter() [2/2]

ns3::SatIslArbiter::SatIslArbiter

(

Ptr< Node >

node

)

Constructor.

Parameters

node	The satellite node this arbiter is attached

Definition at line 50 of file satellite-isl-arbiter.cc.

References m_nodeId.

Member Function Documentation

BaseDecide()

int32_t ns3::SatIslArbiter::BaseDecide	(	Ptr< Packet >	pkt,
		Mac48Address	destination
	)

Base decide how to forward.

Parameters

pkt	Packet
destination	IP header of the packet

Returns

ISL interface index, or -1 if routing failed

Definition at line 58 of file satellite-isl-arbiter.cc.

References Decide(), and m_nodeId.

Here is the call graph for this function:

Decide()

virtual int32_t ns3::SatIslArbiter::Decide ( int32_t  sourceSatId, int32_t  targetSatId, Ptr< Packet >  pkt  )

pure virtual

Decide how to forward.

Implemented in subclasses

Parameters

sourceSatId	Satellite ID where the packet originated from
targetSatId	Satellite ID where the packet has to go to
pkt	Packet

Returns

ISL interface index, or -1 if routing failed

Implemented in ns3::SatIslArbiterUnicast.

Referenced by BaseDecide().

Here is the caller graph for this function:

GetTypeId()

TypeId ns3::SatIslArbiter::GetTypeId ( void  )

static

Definition at line 37 of file satellite-isl-arbiter.cc.

StringReprOfForwardingState()

virtual std::string ns3::SatIslArbiter::StringReprOfForwardingState ( )

pure virtual

Convert the forwarding state (i.e., routing table) to a string representation.

Returns

String representation

Implemented in ns3::SatIslArbiterUnicast.

Member Data Documentation

m_nodeId

uint32_t ns3::SatIslArbiter::m_nodeId

protected

Definition at line 82 of file satellite-isl-arbiter.h.

Referenced by SatIslArbiter(), BaseDecide(), and ns3::SatIslArbiterUnicast::StringReprOfForwardingState().

---

The documentation for this class was generated from the following files:

• /builds/sns3/satellite/satellite/model/satellite-isl-arbiter.h
• /builds/sns3/satellite/satellite/model/satellite-isl-arbiter.cc
